Description
Pipe Camera Kit HD Pro
The Camtek Pipe Camera Kit HD Pro is a portable inspection system for plumbers, drain maintenance contractors and property maintenance teams. Inspect inside drains, pipes and ducting to help identify blockages, visible damage and other issues, then record your findings for customers or future reference.
With Full HD 1080p video, a bright 8-inch colour monitor and a choice of 20m or 40m push cable, the HD Pro combines live viewing, recording and playback in one convenient unit.
Full HD Camera with Adjustable Lighting
The 2-megapixel camera captures detailed Full HD images, while its wide 123° viewing angle provides a broad view of the pipe interior. Nine adjustable white LEDs allow you to control the lighting to suit inspection conditions.
8-Inch Colour Monitor
View live footage on the bright 8-inch TFT/LCD monitor with 1280 × 800 display resolution. Review recorded videos and photos directly on the unit while you are still on site. An HDMI output also allows connection to an external display.
Video, Photo and Audio Recording
Record inspections in Full HD MP4 format, capture still images and add spoken commentary using the built-in microphone. Save your footage to USB storage or a microSD/TF card for easy transfer, sharing and record-keeping. Storage capacities up to 512 GB are supported.
Built-In Distance Counter
Track how far the camera has travelled using the built-in distance counter, with readings in metres or feet. Reset the counter at your starting point to help record the approximate position of an issue along the pipe.
Rechargeable Battery
The integrated 12V, 8,000 mAh rechargeable lithium battery provides approximately 5–6 hours of operation on a full charge, depending on use.
Key Specifications
- Cable length: 20m standard; optional 40 m upgrade
- Push cable diameter: 5.2 mm
- Camera resolution: 1920 × 1080 Full HD, 2 megapixels
- Viewing angle: 123°
- Camera lighting: 9 adjustable white LEDs
- Monitor: 8-inch TFT/LCD colour display
- Monitor resolution: 1280 × 800
- Recording: MP4 video, still images and microphone audio
- Storage: USB or microSD/TF card, up to 512 GB
- Distance counter: Metres or feet, with reset function
- Battery: 12V, 8,000 mAh rechargeable lithium battery
- Operating time: Approximately 5–6 hours per full charge
- External display connection: HDMI output
- Locating option: Camera head with built-in sonde; compatible locator required and sold separately
Choice of 20m or 40m Cable
The standard kit comes with a 20m push cable.
Upgrade to a 40m cable for an additional $450 for inspections requiring greater reach.
Both options use a 5.2 mm fibreglass push cable housed in a compact reel, with a convenient carry handle for transport between jobs.
Optional Camera Head with Locating Sonde
This transmitter allows the camera head to be located underground using a compatible locator, helping pinpoint the position of a blockage or damaged section identified during inspection.
Upgrade to a camera head with a built-in sonde for an additional $350.
A compatible locator is required and is sold separately.
View our Entry Level Inspection Camera Locator
Optional Upgrades
- 40m cable upgrade: Add $450
- Camera head with built-in sonde: Add $350
- Compatible Locator: Add $1,650
Please note: Upgrade prices are additional to the standard kit price.
Local Support, Repairs and Spare Parts
Supplied by Camtek Surveillance Products in Adelaide, with local product advice, workshop repairs and access to replacement parts. We work closely with our manufacturer to support your equipment and help keep it working.
Contact Camtek to discuss cable lengths, camera head options, and the right setup for your inspection requirements.
